Pipe Clamps and Accessories

Stabil D-M16 w/ Lining

Application

For soundproof installation of pipes in M&E services and plant construction.

Scope of delivery

With sound absorption lining; with welded on M16 nut; clamping bolts and nuts included in loose form. Other welded nuts (e.g. M20) or inch sockets available on request.

Technical Data

Size range
[mm]
Max. adm.
load (tension)
Tightening torque
[Nm]
320 - 407 9 kN 20
410 - 521 15 kN 20

The max. admissible load has been determined by using statistical methods resulting from the breaking loads, observing a max. admissible deformation of 1.5 mm resp. 2 % of the max. tensible pipe dia.

Material:
Metal components:
Steel, electro-galvanised
Sound absorption lining:
SBR/EPDM (black) - (see chapter "Sound Absorption Products")
Size range
[mm]
Material
W x th
[mm]
Clamping
bolts
B
[mm]
L
[mm]
W
[kg]
Quantity
[pack]
Part
number
320 - 32650 x 5M16 x 604544043.101 103987
345 - 35650 x 5M16 x 604824323.131 103996
359 - 36850 x 5M16 x 604964463.571 104003
398 - 40750 x 5M16 x 605344843.661 104012
410 - 41970 x 6M16 x 605464965.951 104021
498 - 50870 x 6M16 x 606315816.971 104030
512 - 52170 x 6M16 x 606455957.431 104049
