Support Bracket WK 150/150 A4
Group: 1726
Part number 193655
Suitable for wall, floor and ceiling mounting with various pipe positions
Flexible mounting options in combination with channel
Technical Data
B | 40 mm |
b | 13 mm |
H | 150 mm |
H1 | 25,25 mm |
H2 | 59,75 mm |
H3 | 94,25 mm |
H4 | 128,75 mm |
L | 150 mm |
L1 | 25,25 mm |
L2 | 59,75 mm |
L3 | 94,25 mm |
L4 | 128,75 mm |
t | 4 mm |
Technical specifications
Permissible stress σ{perm.} | 160,00 N/mm² |
Primary element material | Stainless Steel A4 |
Corrosion protection class | CRC II – III (C4 – C5 acc. to DIN EN ISO 12944-2) |
