Application

For pipeline systems in industrial and residential buildings and Sprinkler installations meeting the VdS and FM standards.
For horizontal and vertical pipelines, the U-Bolts are applied as Fixed Points and as Guiding Supports.

Scope of delivery

Four hexagon nuts included in loose form.

Installation

When used as Guided Support, nuts have to be arranged and fixed on both sides, at the top and at the bottom of the profile. Thereby the pipe should remain flexible. When used as Fixed Point the admissible loads of the connecting elements shouldn't exceed the bending loads of the U-bolt.

Technical Data

Material:
Stainless steel A4
Specification:
Similar to DIN 3570 standard

Approvals / Conformity

Size NB 8" with M12 thread obtained a separate VdS Approval: No. G4810047

U-Bolt - G4810047 VdS PDF | 1.1 MB

TypeNBB
[mm]
L1
[mm]
L2
[mm]
ThreadW
[kg]
Quantity
[pack]
Part
number
21.3 1/2" 30 4530M 80.0550 102719
26.9 3/4" 35 6040M 80.0750 102728
33.7 1" 42 6740M 80.0750 102737
42.41 1/4" 51 7640M 80.0850 102746
48.31 1/2" 57 8240M 80.0850 102889
60.3 2" 71 9545M 100.16 50 102898
76.12 1/2" 8711145M 100.18 50 102904
88.9 3"10012345M 100.20 50 102913
114.3 4"12615755M 120.3525 102694
10812115155M 120.34 50 102922
139.7 5"15218055M 120.39 25 102931
13314617255M 120.39 25 102685
15917219755M 120.42 25 102940
168.3 6"18020755M 120.4410 102700
219.1 8"23326755M 120.5510 102959
274.010"30231470M 201.88 10 102968
