WK CC - 100/100-40
Support Bracket WK CC - 100/100-40
Group: 1326
Part number 191774
Suitable for use in connection with Sikla Channels
Versatile options for cantilevered brackets in combination with channel
Technical Data
B | 40 mm |
b | 11 mm |
H | 100 mm |
H1 | 23,5 mm |
H2 | 53,5 mm |
H3 | 83,5 mm |
L | 100 mm |
L1 | 23,5 mm |
L2 | 53,5 mm |
L3 | 83,5 mm |
t | 2,5 mm |
Technical specifications
Primary element material | steel |
Connecting element material | steel |
Surface finish | electro galvanized (Fe//Zn) |
Corrosion protection class | C2 |
Certification
