Insulated Foot Plate SHB F 80 220 HCP
Group: A440
Part number 198926
Integrated footplate provide a solution for the support of building services
Permeable rubber compound mat to provides secure support and even load distribution
Technical Data
bP | 14 mm |
BP | 220 mm |
BP1 | 170 mm |
dP | 14 mm |
HP | 220 mm |
HP1 | 170 mm |
IZP | 30 mm |
LG | 218 mm |
tP | 12 mm |
TS | 15 mm |
Load range
VZ,perm. | 34,60 kN |
Technical specifications
Fire Performance | B2 according to DIN 4102 |
Tensile Resistance | 0,40 N/mm² |
Tear Resistance | 3,40 N/mm |
Elongation at break | 70 % |
Compression set | approx. 4.0 % measured 30 min. after release at 50 % compression / 23°C after 72 hours |
Material base body | steel |
Material insulation body | SBR |
Surface | HCP |
Corossion class | C4 |
Certification
Installation
Assembly to Beam Section TP F 80 by means of 4 Self Forming Screws FLS F.
The system-related static friction must be determined on site. Depending on the roofing membrane used, the use of an additional separating layer is recommended. The load transfer into the structure must be checked on site.
