Fixing Bracket MW 90/90/45° A4
Group: 1726
Part number 105721
Useful addition to support brackets for integration in crossbars and other structures composed of stainless steel channels
Technical Data
B | 40 mm |
H | 90 mm |
H1 | 25,75 mm |
H2 | 40 mm |
L | 90 mm |
L1 | 25,75 mm |
L2 | 40 mm |
t | 4 mm |
W | 45 ° |
Technical specifications
Primary element material | Stainless Steel A4 |
Corrosion protection class | CRC II – III (C4 – C5 acc. to DIN EN ISO 12944-2) |
Certification
