Duo Clamp SRS ME 110-115 A4
Group: 1722
Part number 170790
Two-piece pipe clamp with thread connection M8 or M10 for pipeline installation
Includes sound absorption lining for noise reduction
Technical Data
B1 | 173 mm |
b2 | 28 mm |
D | 114 mm |
D2 | 114 mm |
e | 153 mm |
H | 148 mm |
Mi1 | M10 |
t | 2,5 mm |
Supplied with two bolts partially mounted on one side and therefore ready for immediate installation. The clamping bolt on the open side is retained by a plastic washer, thus preventing any accidental unscrewing.
Load range
-VZ,perm. | 2,50 kN |
Technical specifications
Material base body | Stainless Steel A4 |
Material insulation body | SBR/EPDM |
Material connecting element | Stainless Steel A4 |
Corossion class | CRC II – III (C4 – C5 acc. to DIN EN ISO 12944-2) |
Certification
Installation
Tightening torque: 2 Nm
