Ducting Strap LUB
Group: 1603
Part number 151582
Suitable if soundproof installation according to DIN 4109 is demanded
Enables mounting of threaded rod close to a ceiling, or for suspended installation
Technical Data
B1 | 189 mm |
b1 | 25 mm |
B2 | 26 mm |
d | 9,5 mm |
d1 | 4 mm |
d2 | 10,1 mm |
H | 47 mm |
H1 | 15 mm |
t | 2,5 mm |
Sound absorption component with carrying bracket and distance bush pre-assembled.
Load range
-VZ,perm. | 0,30 kN |
Technical specifications
Material base body | steel |
Material insulation body | TPE |
Surface | pre-galavanised |
Corossion class | C2 |
Certification
Installation
The use of 2 x 3 blind steel rivets of 4 mm is recommended.
Connection bush: 10,5
Thread connection: M8 or M10
