Support Bracket WK 200/200
Group: 1326
Part number 118170
May be used for wall, floor and overhead pipe installation
Versatile mounting options through combination with channel
Technical Data
B | 60 mm |
b | 13 mm |
d | 17 mm |
H | 210 mm |
H1 | 31 mm |
H2 | 81 mm |
H3 | 131 mm |
H4 | 181 mm |
L | 210 mm |
L1 | 31 mm |
L2 | 81 mm |
L3 | 131 mm |
L4 | 181 mm |
t | 4 mm |
For load values, see additional documents.
Technical specifications
Permissible stress σ{perm.} | 160,00 N/mm² |
Primary element material | steel |
Surface finish | electro galvanized (Fe//Zn) |
Corrosion protection class | C2 |
Certification
Documents
Datasheets / Loads
- Angle Bracket WK - Sikla Product Details (200-200)
PDF (0.18MB)
