GLE LC-I
Slide Element GLE LC-I
Group: 1343
Part number 151078
Suspension slide element for ceiling or Sikla Channel mounting in parallel pipe runs
Pendular function allows slight lateral movements
Slide roller ensures smooth, jerk-free and silent sliding; Type LC-A suitable for insulation thicknesses up to 25 mm
Technical Data
Completely pre-assembled.
Load range
-VZ,perm. | 1,00 kN |
Technical specifications
Material base body | steel |
Material connecting element | steel |
Surface | electro galvanized (Fe//Zn) |
Corossion class | C2 |
Certification
Installation
Type LC-I allows for height adjustment by offering a screw depth of up to 15 mm. For fixing the position of the Slide Element, a locking nut has to be used.
Sliding distance: Max. 25 mm
Maximum swinging angle: 2°
